144C Fiber Cable
The double-jacketed trunk cable has a more robust and durable sheath that can provide higher compressive strength. These cables are usually designed for longer cable lengths between cabinet applications or connect different building areas.
View Detail
180° Cat.6A STP Keystone Jack, Tool-Free, GHMT PVP
Features
• High-Density design for 1U-48port keystone panel, extreme performance design for Hyper-Scale and Edge Data Center
• GHMT PVP(PREMIUM Verification Program) verified ISO/IEC 11801-1 and IEC 60603-7-51 Cat.6A Connecting-Hardware including the 4PPoE performance
• 100% Cat.6A performance tested in factory
• Perfect EMC performance by the full shielded of zinc Die-Casting material and grounding block design
• Easy and Tool-Free in field termination, T568A & B wiring
• Power over HDBaseT (PoH) applications up to 100 watts
• UL 1863 verified
180° STP Connecting-Hardware Keystone Jack, Tool-Free, Cable-Clamper Type, EC verified
Features
• High-Density design for 1U-24port keystone panel, extreme performance for Edge Data Center
• EC verified ANSI/TIA-568.2-D Connecting-Hardware including the 4PPoE performance
• Quick and efficient installation by Cable-Clamper structure, Fool-Proofing and Pre-Lock design of IDC-cap
• Hi-Pot insulation performance improved by IDC’s Housing-Wall design
• 22-26AWG stranded and solid wires range
• T568A & B wiring
• Power over HDBaseT (PoH) applications up to 100 watts
• UL 1863 verified
180° STP Connecting-Hardware Keystone Jack, Tool-Free, Dust-Cap Type, EC verified
Features
• High-Density design for 1U-24port keystone panel, extreme performance design for Hyper-Scale and Edge Data Center
• EC verified ANSI/TIA-568.2-D Connecting-Hardware including the 4PPoE performance
• Easy and Tool-Free in field termination, T568A & B wiring
• Power over HDBaseT (PoH) applications up to 100 watts
• UL 1863 verified
• IP20 by Dust-Cap design
