Description
• Push-pull boot for easy installation and removal without tools or pull tabs
• Change the LC A/B polarity without exposing or twisting fibers to ensure high performance
• The compact design is specifically engineered to maximize available space in high-density (HD) panels
• Ultra Low Loss LC ferrule, IEC 61753-1 random mating IL (Insertion Loss) Grade B
• 1.6mm cable O.D. improve airflow, routing and maximize valuable space
• Compared with traditional zip-cord cable, round duplex cable reduces the number of cables in half and optimizes space by 68%
• Simplifies cable management, Reduces weight and lower carriage costs
• Options with MM OM3, OM4, OM5 bend-insensitive fiber and SM OS2 G657A fiber
• 100% Factory terminated and tested to ensure quality
BIMMF OM3/OM4/OM5 | OS2 G.657.A |
|||
|---|---|---|---|---|
| Standard Loss | Low Loss | Standard Loss | Low Loss | |
| Insertion Loss | < 0.3 dB | < 0.15 dB | < 0.2 dB | < 0.15 dB |
| Return Loss | > 35 dB | > 35 dB | UPC > 55 dB APC > 60 dB | UPC > 55 dB APC > 60 dB |
